KNX Switch Actuator 4/8/12-Fold, 16A
KNX Switch Actuator 4/8/12-Fold, 16A
KNX Switch Actuator 4/8/12-Fold, 16A
KNX Switch Actuator 4/8/12-Fold, 16A
KNX Switch Actuator 4/8/12-Fold, 16A
KNX Switch Actuator 4/8/12-Fold, 16A

KNX Switch Actuator 4/8/12-Fold, 16A

Manual&Database

16A/channel, un rated voltage 250V AC, 50-60Hz, high-current magnetic relay, max. switching current 20A switching/heating actuator operation mode. Main KNX functions including switching, status response, scene control (5 folds), time switching, preset, logic function, threshold, forced operation etc. Installation: DIN-rail Mounted

Description




Switch Actuator, 4fold

KA/R 0416.2

Switch Actuator, 8fold

KA/R 0816.2

Switch Actuator, 12fold

KA/R 1216.2


  • Manual switch operation

  • Switch and Status response

  • Reaction after bus voltage failure and recovery

  • Scene and preset control

  • Logic operation with AND, OR, XOR, gate function

  • Forced operation and Safety function

  • Threshold and time function

  • Control of electro thermal valve drives


share
Additional information
  • Bus voltage
    21-30V DC, Via KNX bus
  • Bus current
    <12mA
  • Bus consumption
    <360mW
  • Un rated voltage
    250V/440V AC (50/60Hz)
  • In rated current
    20A
  • Load capacity
    16A/200uF
  • Max.switching current
    40A/250V AC
  • Machanical endurance
    >100x10000
  • Electrical endurance
    >1x10000
  • Model
    KA/R 0416.2、KA/R 0816.2、KA/R 1216.2
