KNX Room Controller Smart 3.0
KNX Room Controller Smart 3.0

KNX Room Controller Smart 3.0

Manual&Database

Switch relay 4 * 16A,21 * 6A; 1 folds AC/Dry contact shutter, 2 folds TRIAC dimming, 3 folds 0-10V dimming, 1 fold fan coil actuator with 0-10V output valve, 1 fold IP protocol, 5 folds of dry contact/binary input/LED output 4 group event,4 logic functions, 4 time functions,Three-wires PT1000 temperature sensor interface.

Description

  • Dry contact inputs

  • Binary inputs

  • LED indications

  • Switch outputs

  • Shutter control outputs

  • TRIAC dimming outputs

  • Fan coil output

  • 0-10V drive interface as dimming outputs or fan coil output

  • Logic, Time and Scene group functions

  • Support KNXnet/IP Tunneling

  • Support KNXnet/IP Router

share
Additional information
  • Bus voltage
    21-30V DC, Via KNX/EIB
  • Bus current
    <12mA
  • Bus consumption
    <360mW
  • Auxiliary voltage
    24-30V DC
  • Auxiliary current
    <200mA
  • Input
    5ch Binary Input，with 5ch LED indicator
  • Output
    25ch switch outputs(4ch is 16A, rated voltage is 250VAC; other 21ch is 6A, rated voltage is 240VAC)，some channel can be also use as shutter, fan cont
  • Output
    3ch 0-10VDC outputs, rated current is 50mA, can be used as dimming or fan coil output
  • Output
    2ch Triac Dimming outputs, max.100W per channel
  • Mode
    AMRS-41/05.3
